WIDTH 650 mm
HEIGHT 786 mm
DEPTH 80 mm
WEIGHT 6 kg
DESCRIPTION installation onto or in front of a solid brick wall
M12 WC fastening materials, fastening materials, reinforcing mesh, without flush plate
EN 14055
individual packaging materials
For combination with: for wall-mounted WC
comprising a U-shaped galvanized support frame with 6 fastening lugs
front operated
with pre-assembled concealed cistern with insulation against condensation with dual flush 3/6 l, adjustable to 3/4,5 l, maximal flush quantity 7.5 l, filling valve Noise Class I, flexible hose for filling valve, can be tightened by hand, mounting clip, 4 adjustment settings, protection box for access opening can be cut to size, WC connecting bend 90° DN 90 (Ø 90) / with reducing sleeve DN 90 (Ø 90) / DN 110 (Ø 110) with protection cap, complete WC connection set DN 90 (Ø 90) / 180 mm, c
